D6 Labs™Engineered IoT SolutionsWhskeroTMwww.d6labs.comPage 1sales@d6labs.com© Copyright 2026 Digital Six Laboratories, All Right Reserved1-844-365-8647WBP-TR-01-6I7.6 Centimeter Thermistor Temperature Probe, 15.2 Centimeter CableD6 Labs Probe ShortGeneral DescriptionThis external sensor is designed to work with a Whisker.Block® that is configured with an external thermistor (TR) input. When properly mounted, this sensor can detect temperatures in the range of -40 to 85 degrees celsius. The thermistor is contained within a 7.6 centimeter stainless steel housing that can be used in air, food products, and most liquids. It is available with a 15.2 centimeter and 91.4 centimeter cable.We offer other temperatures probe configurations that can be used in a variety of applications. The WBP-TR-02-xx is a 12.7 centimeter version of this probe, the WBP-TR-03-xx is designed to be mounted in HVAC ducts, and finally the WBP-TR-04-xx is a lug mounted probe that can be used on equipment such as motors.PowerPower for the sensor is provided by the Whisker.Block®.MountingThe sensor is housed in a 6.10 millimeter round by 7.6 centimeter long stainless steel tube.It should be mounted so that the bottom half the tube is fully submerged in the medium you are monitoring.Take care not to crimp or otherwise damage the stainless steel tube as that might adversely affect proper operation or might shorten the operating life of the sensor.Compatible Whisker.Blocks®Part NumberWB1-9-xx-TRNNNNNN-0000-xxWB1-9-xx-TRTRNNNN-0000-xxWB1-9-xx-DCTRNNNN-0000-xxWB1-9-xx-DCTRTRNN-0000-xxWB1-9-xx-DCTRTRNN-7000-xxWB1-9-xx-C1TRTRNN-0000-xxWB1-9-xx-C2TRTRNN-0000-xxWB1-9-xx-C3TRTRNN-0000-xxWB1-9-xx-C4TRTRNN-0000-xxWiringD6 Labs Probe-Short DiagramRecommended Wiring:ConnectorPinSensor WireDescription11RedSensor power supply12 or 3Blue/BlackThermistor output
