D6 Labs™Engineered IoT SolutionsWhskeroTMwww.d6labs.comPage 1sales@d6labs.com© Copyright 2026 Digital Six Laboratories, All Right Reserved1-844-365-8647WH1-9-00-Ixxxx-NSmart.Hub™ Industrial, Ethernet or Cellular InterfaceD6 Labs Spec Sheet Industrial HUB DrawingGeneral DescriptionThe Smart.Hub™ Industrial is a rugged, versatile and reliable IOT gateway device for use in outdoor applications. Smart.Hub™ products are gateways used to move data from Whisker.Block® sensor blocks and end user customized Whisker Engine based sensor nodes to the Whisker.io® cloud platform. The Smart.Hub™ Industrial has versatile power options and can be configured with multiple power options including 8-24 VDC, 85-240 VAC and PoE.Features•Plug and play operation•Ethernet & Cellular options•Data buffering during loss of connectivity•Supports all Whisker.io® Cloud services•Works with 3rd party platforms via Whisker.io® Forwarding•Supports two-way communication with field devices & monitor and control•Communicate with field devices over distances more than 1 mile.•Integrated MQTT, ModbusTCP and SparkPlugB(Ignition) protocols. •IP65 rate enclosure, wall and pole mounting•Flexible power options◦Power over Ethernet◦8-32 VDC◦85-240 VACRobustness and ReliabilityThe Smart.Hub™ Industrial can be configured with primary and secondary connections to the cloud through ethernet or cellular. When two connections are configured the hub will support automatic failover to the secondary connection. If all configured connections are lost, the hub will buffer messages in internal non-volatile memory until cloud connectivity is restored. In the event of catastrophic failure, the data from the internal SD card can be recovered using a Windows based Data Recovery App. The Smart.Hub™ can be configured with battery back-up that will allow the hub to continue normal operation for up to 24 hours. If power is lost on hubs equipped with battery back-up, the hub will notify the Whisker.io® cloud of the failure, allowing text and email alerts to be sent to specified contacts.Throughput[The number of devices that can be supported by this hub varies with the reporting rate of the connected devices., This is a single channel hub, which ultimately determines its limitations; with a single channel, this hub can process about 1,800 messages an hour., The following table estimates device capacity for several different update rates.]Update RateEstimated number of devices5 Minutes1001 Hour10004 Hours250024 Hours7500This hub supports two-way communications with field devices that support the Whisker.io® protocol. For battery powered devices, the hub will queue down-stream messages (commands) and send them to the device when it reports in at its sampling interval; therefore, the command latency is equivalent to the update rate of the device. For line powered devices, commands are sent immediately, with a latency of less than 1 second.Whisker.io® ServicesStorageDevices that are configured with the storage service will persist their historic data in the Whisker.io® cloud, making it available for visualization and analysis using our Whisker.io® Portal web-based software.AlertingRules based alerting allows a text or email to be sent when the specified condition is met and when it clears.DashboardSecure, user friendly dashboard with visualization through gauges, graphs, sensor signal strength and fuel gauges.ProtocolsThe Whisker.io® Smart.Hub™ provides several protocols to support IIoT applications: Modbus TCP for PLC/HMI, SparkPlugB for Ignition, and MQTT for IoT.
WhskeroTMwww.d6labs.comPage 2sales@d6labs.com© Copyright 2026 Digital Six Laboratories, All Right Reserved1-844-365-8647Product AttributesTypeDescriptionSeriesWhisker.io®FeaturesIoT Commercial Gateway, Built-In Data Buffering, Long Range, Supports Multiple Whisker.Block® Devices & Industrial Protocols (Modbus TCP, MQTT, SparkplugB)FunctionGatewayApplicationsGeneral Purpose, IndustrialEnvironmentIndoor / OutdoorFrequency Range902-928 MHzInterfacexxSupported DevicesVaries based on application and update rateData BufferingYesVoltage Supply8-32 VDCPower SupplyOptional (internal or external) power supplyEnclosureIP65 CaseOrder InformationPart NumberDescriptionWH1-9-00-IANEN-NWhisker.io®, Smart.Hub™ Industrial, 900 MHz, AC Power, Ethernet, 120VACWH1-9-00-IANCN-NWhisker.io®, Smart.Hub™ Industrial, 900 MHz, AC Power, Cellular, 120VACWH1-9-00-IDNEN-NWhisker.io®, Smart.Hub™ Industrial, 900 MHz, DC Power, Ethernet, 120VACWH1-9-00-IDNCN-NWhisker.io®, Smart.Hub™ Industrial, 900 MHz, DC Power, Cellular, 120VAC
