SS1-1-900-U
Universal Handwash
D6 Labs Universal-Soap-Sensor
General Description
The Universal Soap Dispenser Sensor is an IOT enabled device that is
mounted adjacent to any hand soap dispenser and counts the
number of times soap is dispensed by sensing the presence of hands
moving to and away from the soap dispenser.
The dispenser communicates to the cloud platform through our
Smart.Hub™ family of cloud connected IOT hubs. It periodically
communicates a message to the Smart.Hub™ indicating the battery
voltage and the count of dispenses since it first began operation.
This information can be used as a means of determining how much
product has been dispensed since the last refill or to determine use
frequency and time of day patterns to ensure hand wash policy
compliance.
The long range, exceptional battery life and reliability make it the
perfect choice for organizations looking for insight into the hygiene
practices.
Power
The Universal Soap Dispenser is powered internally using a 3.7V,
5.2A-H LiThCl battery pack that should give 10+ years of service life
before a battery change is required, assuming a 5 minute average
dispense period.
Internal Channels
This device is configured with
two (2)
internal channels:
V
DC
Battery Voltage
1 2 3...
Dispenser Count
Mounting
The Universal Soap Dispenser is mounted next to the
device such that the infra-red sensor is pointed toward
the area where a hand would be placed to acquire soap.
The device should be mounted between 1 to
1.6 millimeters
from the soap dispensing area. Note:
the Universal Hand Dispenser must be mounted within
range of a Smart.Hub™ for it's reading to be passed
through the Cloud platform, and viewed in the Web
Portal.
Electrical Specifications
Parameter
Minimum
Typical
Maximum
Units
Battery Life Standard Pack
10
20
Years
Operating Temperature Range
-4
85
Degrees Fahrenheit
Transmission Range
1
.8 km
-
1.6 km
Miles
Frequency Range
902
928
MHz
Sensor Sample Rate
5
Minutes
1) Typical range: Outdoors, external antenna, line of sight, unobstructed, antenna elevation
3 meters
.
Order Information
Part Number
Description
SS1-1-900-U
Universal Handwash, 900MHz, Battery powered, int. antenna
