D6 Labs™Engineered IoT SolutionsWhskeroTMwww.d6labs.comPage 1sales@d6labs.com© Copyright 2026 Digital Six Laboratories, All Right Reserved1-844-365-8647WBP-WL-02-3FH20 Leak Detection, 91.4 Centimeter H2O Leak sensor rope, 1.5 Meter CableD6 Labs Rope-Water-Leak DrawingGeneral DescriptionThis external sensor is designed to work with a Whisker.Block® that is configured with an external dry contact (DC) input. When properly mounted on a pipe or surface, the sensor will detect water on contact.When there is no water present, the DC channel will indicate a "low" state. When water is present, the DC channel will indicate a "high" state.Alertnatively, you can use WBP-WL-01-3F if you need to monitor standing water that may collect on the floor or a surface. That sensor is a Puck-type H20 detector that can be installed just above the surface in question.PowerThis is a passive sensor that requires no external power. MountingThis sensor is designed to mount by wrapping or stapping onto a pipe, tube, or surface where water may run if a leak occurs.Compatible Whisker.Blocks®Part NumberWB1-9-xx-DCNNNNNN-0000-xxWB1-9-xx-DCDCNNNN-0000-xxWB1-9-xx-DCTRNNNN-0000-xxWB1-9-xx-DCTRTRNN-0000-xxWB1-9-xx-DCTRTRNN-7000-xxWB1-9-xx-DCA4NNNN-0000-xxWB1-9-xx-DCA4A4NN-0000-xxWB1-9-xx-DCDCA4A4-0000-xxWB1-9-xx-DCA5NNNN-0000-xxWB1-9-xx-DCA5A5NN-0000-xxWiringD6 Labs Rope-Water-Leak DiagramRecommended Wiring:ConnectorPinSensor WireDescription12 or 3Blue/BlackDry Contact In14WhiteGround Reference
